securityNET installation twisted-pair cable is designed for connections between multimedia signal distribution points and user connection sockets. The U/UTP (unshielded) twisted-pair cable is suitable for installation in computer networks, telephone networks, CCTV systems, etc., which are not exposed to electromagnetic interference. It has an LSZH Dca outer jacket. The cable meets the requirements specified by the structured cabling standards: ISO/IEC 11801, EN 50173, EIA/TIA 568-C.2.
Tested and proven quality
Optimal choice for indoor applications
Wide range of application
Resistant to damage
A dependable network you can trust
The securityNET twisted pair cable is made of the highest quality copper, making it the optimal choice for building connections designed to last for years. It has undergone rigorous strength tests over a 90-meter length using a Fluke Networks DSX-8000 meter. Therefore, if you are seeking materials with exceptional durability, this is an excellent option.
Low smoke, zero halogen (LSZH) jacket for enhanced safety
Compliant with EU CPR regulations, our LSZH (Low Smoke Zero Halogen) cables offer enhanced safety by minimizing fire hazards and toxic emissions. In the event of a fire, these cables significantly reduce the spread of flames and generate minimal smoke and harmful fumes, protecting building occupants and facilitating safe evacuation. securityNET provides a comprehensive range of LSZH cables, designed to meet the specific requirements of your project, ensuring both safety and compliance.
|
Outer diameter |
5,8mm
|
|
Category/class |
6 (E class)
|
|
Shielding |
U/UTP
|
|
Copper conductor thickness/AWG |
0,55mm/AWG23
|
|
Wires |
solid wire
|
|
Conductors |
copper
|
|
Conductor insulation |
HDPE 0,95mm
|
|
Coating thickness |
0,55mm
|
|
Outer sheath |
LSZH
|
|
CPR class |
Dca
|
|
Cable construction |
4x2
|
|
Bend radius at installation |
47mm
|
|
Impedance |
100Ω
|
|
Delay Skew |
≤45
|
|
Nominal propagation velocity (NVP) |
68%
|
|
Linear Resistance (max.) |
9,5 (Ω/100m)
|
|
Pair separator |
yes
|
|
Operating temperature |
from -20°C to 70°C
|
|
Installation temperature |
from 0°C to 50°C
|
|
Quantity per package |
500m
|
|
Insulation color |
RAL 7035
|
|
RoHS |
yes
|
