securityNET F/UTP category 6 PVC cable 305m

SecurityNET installation twisted-pair cable is designed to make connections between distribution points for multimedia signals and users’ connection outlets. F/UTP twisted pair cable (shielded) is suitable for installation in computer networks, telephone networks, CCTV systems, etc., which are exposed to electromagnetic interference. Featuring a durable PVC outer jacket, this cable is designed to meet the demanding standards of ISO/IEC 11801, EN 50173, and EIA/TIA 568-C.2, ensuring optimal performance in various applications.

securityNET F/UTP category 6 PVC cable 305m

A dependable network you can trust

The securityNET twisted pair cable is made of the highest quality copper, making it the optimal choice for building connections designed to last for years. It has undergone rigorous strength tests over a 90-meter length using a Fluke Networks DSX-8000 meter. Therefore, if you are seeking materials with exceptional durability, this is an excellent option.

securityNET F/UTP category 6 PVC cable 305m

Wide range of applications

Shielded Category 6 F/UTP cable is engineered for high-performance indoor networks, delivering up to 10 Gb/s. Its robust construction makes it resistant to electromagnetic interference, making it suitable for demanding applications such as computer networks and telephony. The combination of quality and affordability makes it a preferred choice for professionals.



Technical specifications

Outer diameter

Outer diameter

7,4mm
Category/class

Category/class

6 (E class)
Shielding

Shielding

F/UTP
Copper conductor thickness/AWG

Copper conductor thickness/AWG

0,565mm/AWG23
Wires

Wires

solid wire
Conductors

Conductors

copper
Conductor insulation

Conductor insulation

HDPE 1,12mm
Coating thickness

Coating thickness

0,6mm
Outer sheath

Outer sheath

PVC
CPR class

CPR class

Eca
Cable construction

Cable construction

4x2
Bend radius at installation

Bend radius at installation

60mm
Impedance

Impedance

100Ω
Delay Skew

Delay Skew

≤45
Nominal propagation velocity (NVP)

Nominal propagation velocity (NVP)

68%
Linear Resistance (max.)

Linear Resistance (max.)

9,5 (Ω/100m)
Pair separator

Pair separator

yes
Operating temperature

Operating temperature

from -15°C to 60°C
Installation temperature

Installation temperature

from 0°C to 50°C
Quantity per package

Quantity per package

305m
Insulation color

Insulation color

RAL 7035
RoHS

RoHS

yes
