96J fiber optic coupler equipped with 4 round ports

The fiber optic coupler is an advanced solution designed to protect the splices of trunk and distribution fiber optic cables. Equipped with airtight heat-sealed ports, this shield is ideal for overhead, duct and metered installations. Made of UV-resistant polypropylene (PP), the shield provides excellent protection even in extreme conditions. The product is suitable for a wide temperature range, from -40°C to +60°C, and shows high resistance to chemicals.

The FHSC-435-4-96 shield is ideal for installations in harsh environments, offering high reliability and easy maintenance. With a wide range of installation accessories and high-quality materials, this product is an excellent choice for modern fiber optic networks.

IP68 level waterproofing
Long-term reliability
Resistance to harsh environmental conditions
Complete set of accessories

96J fiber optic coupler equipped with 4 round ports

Hermetically sealed thermally sealed ports

Equipped with thermally sealed inlet/outlet ports that provide high sealing and protection against water and moisture, which is crucial for the longevity of fiber optic installations.

Resistance to environmental conditions

The casing is made of UV- and chemical-resistant polypropylene (PP) and provides excellent protection over a wide temperature range (-40°C to +60°C). This makes the shield suitable for use in a variety of environments, both overhead and ground.

Large capacity and easy installation

The shield has a capacity of up to 96 fibers, separated into four cassettes for convenient operation and fiber management. All necessary accessories for installation are included, including a mounting bracket, heat-sealable sealing tubes, splice covers, and more.

Technical specifications

	Capacity	up to 96 fibers
	Maximum number of cassettes	4 cassettes of 24 fibers each
	Oval ports	1 oval port for two cables with diameters from 8 to 19 mm
	Round ports	4 round ports for a single cable with a diameter from 5 to 19 mm
	Degree of protection	IP66
	Length	420mm (cable seals increase the length of the cover by an additional 100mm)
	Diameter	134mm (without clamp), 190mm (max. with clamp)
	Weight	2.35kg
